Specifications
Technical specifications
Lamp type
mercury
Power consumption, W
87±2
Lamp current, A
0,8±0,1
Overall dimensions by sockets, length/diameter, mm
843±5 / 15±1
Weight, g
150±10
Compatible type of electronic controller
DUV- 1-87-N control panel
Lamp lifetime, hours, not more than
8 000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
95±5
Current through the lamp, A
2,0±0,1
Overall dimensions by sockets, length/diameter, mm
594±5 / 19±1
Weight, g
125±10
Recommended ballast type
EPRA-1х145 / EPRA-L-220-1х300
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
235±10
Current through the lamp, A
1,85±0,1
Overall dimensions by sockets, length/diameter, mm
1600±5 / 19±1
Weight, g
290±20
Recommended ballast type
EPRA-L-220-1х300
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
240±10
Current through the lamp, A
3,2±0,1
Overall dimensions by sockets, length/diameter, mm
1220±5 / 28±1
Weight, g
400±20
Recommended ballast type
EPRA-L-220-1х350
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
210±10
Current through the lamp, A
5,0±0,1
Overall dimensions by sockets, length/diameter, mm
675±5 / 32±1
Weight, g
260±20
Compatible type of electronic controller
DUV- 1A250 control panel
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
240±10
Current through the lamp, A
3,2±0,1
Overall dimensions by sockets, length/diameter, mm
1220±5 / 28±1
Weight, g
400±20
Recommended ballast type
EPRA-L-220-1х350
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
440±12
Current through the lamp, A
5,0±0,1
Overall dimensions by sockets, length/diameter, mm
1600±5 / 28±1
Weight, g
500±25
Recommended ballast type
EPRA-L-220-1х500
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
400±20
Current through the lamp, A
5,0±0,1
Overall dimensions by sockets, length/diameter, mm
1220±5 / 32±1
Weight, g
440±20
Recommended ballast type
EPRA-L-220-1х500
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
Specifications
Technical specifications
Lamp type
Amalgam
Power consumption, W
500±30
Current through the lamp, A
5,0±0,1
Overall dimensions by sockets, length/diameter, mm
1600±5 / 32±1
Weight, g
590±30
Recommended ballast type
EPRA-L-220-1х700
Lamp lifetime, hours/cycles, not more than
16 000 / 5000
